TP-Link Networking Device TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE 56W PoE PS
(No reviews yet)
Write a Review
- Brand:
- TP-Link
- Part Number #
- AS207510
- UPC:
- 845973083212
$56.11
Description
•5 10/100/1000Mbps RJ45 ports
•With four PoE ports, transfers data and power on one single cable
•Working with IEEE 802.3af compliant PDs, expands home and office network
•802.1p/DSCP QoS enable smooth latency-sensitive traffic
•Requires no configuration and installation
What This Product Does
TL-SG1005P is a 5 10/100/1000Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.
Power over Ethernet
4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).
Overload Arrangement
TL-SG1005P has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 56W, a priority will be arranged among the PoE ports, then the system will cut off the power of the lowest-priority port. HARDWARE FEATURES
Interface:5 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Network Media:10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
Fan Quantity:Fanless
Power Consumption:63.31W (max. with 56w PoE device connected)
4.26W (max. no PoE device connected)
External Power Supply:External Power Adapter(Output: 48VDC / 1.25A)
PoE Ports (RJ45):Standard: 802.3 af compliant
PoE Ports: Port1- Port4
Power Supply: 56W
Backbound Bandwidth:10Gbps
Mac Address Table:2K
SOFTWARE FEATURES
Advanced Features:Compatible With IEEE 802.3af Compliant PDs
Priority Function
Mac Address Auto-Learning And Auto-Aging
EEE802.3x Flow Control
802.1p/DSCP QoS
IGMP Snooping
Transfer Method:Store-And-Forward
OTHERS
Certification:FCC, CE, RoHS
Package Contents:TL-SG1005P, Power Adapter, Installation Guide
Consumption:4.26 watts (max. no PD connected)
63.31 watts (max. with 56w PD connected)
Storage Humidity: 5%90%RH non-condensing
Item Dimension (L inchxW inchxH inch)
8 x 5 x 5
Weight
2.00lb
Warranty Information
NA
View AllClose
•With four PoE ports, transfers data and power on one single cable
•Working with IEEE 802.3af compliant PDs, expands home and office network
•802.1p/DSCP QoS enable smooth latency-sensitive traffic
•Requires no configuration and installation
What This Product Does
TL-SG1005P is a 5 10/100/1000Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.
Power over Ethernet
4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).
Overload Arrangement
TL-SG1005P has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 56W, a priority will be arranged among the PoE ports, then the system will cut off the power of the lowest-priority port. HARDWARE FEATURES
Interface:5 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Network Media:10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
Fan Quantity:Fanless
Power Consumption:63.31W (max. with 56w PoE device connected)
4.26W (max. no PoE device connected)
External Power Supply:External Power Adapter(Output: 48VDC / 1.25A)
PoE Ports (RJ45):Standard: 802.3 af compliant
PoE Ports: Port1- Port4
Power Supply: 56W
Backbound Bandwidth:10Gbps
Mac Address Table:2K
SOFTWARE FEATURES
Advanced Features:Compatible With IEEE 802.3af Compliant PDs
Priority Function
Mac Address Auto-Learning And Auto-Aging
EEE802.3x Flow Control
802.1p/DSCP QoS
IGMP Snooping
Transfer Method:Store-And-Forward
OTHERS
Certification:FCC, CE, RoHS
Package Contents:TL-SG1005P, Power Adapter, Installation Guide
Consumption:4.26 watts (max. no PD connected)
63.31 watts (max. with 56w PD connected)
Storage Humidity: 5%90%RH non-condensing
Item Dimension (L inchxW inchxH inch)
8 x 5 x 5
Weight
2.00lb
Warranty Information
NA
