J9974A | HPE R110 AM - wireless router - 802.11a/b/g/n

HPE R110 AM - wireless router - 802.11a/b/g/n - desktop, wall-mountable

(No reviews yet) Write a Review

Brand:

HPE

Part Number #

J9974A

Availability:

In Stock

$225.00 $188.00

- You save $37.00

Description
Read Before Ordering

Description

Main Specifications

Product Description	HPE R110 AM - wireless router - 802.11a/b/g/n - desktop, wall-mountable
Device Type	Wireless router - 4-port switch (integrated)
Enclosure Type	Desktop, wall-mountable
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
Frequency Band	2.4 GHz, 5 GHz
Performance	VPN throughput : up to 30 Mbps ¦ NAT throughput : 920 Mbps
Capacity	IPSec VPN tunnels : 5 ¦ Concurrent sessions : 5 ¦ Virtual interfaces (VLANs) : 4
Network / Transport Protocol	PPTP, L2TP, IPSec, ARP, DHCP, DDNS
Routing Protocol	RIP-1, RIP-2, IGMP, static IPv4 routing, static IPv6 routing, RIPng, MLD
Remote Management Protocol	SNMP 1, SNMP 2c, HTTPS
Features	DHCP support, NAT support, VPN support, PAT support, auto-uplink (auto MDI/MDI-X), Stateful Packet Inspection (SPI), DoS attack prevention, content filtering, MAC address filtering, IPv6 support, VPN passthrough, Wireless Distribution System (WDS) support, URL filtering, IP address filtering, firmware upgradable, MIMO technology, Spanning Tree Protocol (STP) support, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), IPSec NAT-Traversal (NAT-T), Wi-Fi Protected Setup (WPS), DHCP server, Samba support, FTP server, Multiple SSID support, MLD snooping, fanless, Stateful Packet Inspection Firewall (SPIF), Network Access Control (NAC), NTP time synchronization, Maximum Likelihood Demodulation (MLD), Class of Service (CoS), Denial of Service (DoS)
Compliant Standards	IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.1w, IEEE 802.11g, IEEE 802.1x, Wi-Fi CERTIFIED, IEEE 802.11e, IEEE 802.11n
Power	AC 120/230 V ( 50/60 Hz )
Dimensions (WxDxH)	8.5 in x 5.5 in x 1.5 in
Weight	15.87 oz
Manufacturer Warranty	3 years warranty

Extended Specifications

General

Device Type	Wireless router - 4-port switch (integrated)
Enclosure Type	Desktop, wall-mountable
Connectivity Technology	Wireless, wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
Frequency Band	2.4 GHz, 5 GHz
Performance	VPN throughput : up to 30 Mbps ¦ NAT throughput : 920 Mbps
Capacity	IPSec VPN tunnels : 5 ¦ Concurrent sessions : 5 ¦ Virtual interfaces (VLANs) : 4
MAC Address Table Size	2048 entries
Network / Transport Protocol	PPTP, L2TP, IPSec, ARP, DHCP, DDNS
Routing Protocol	RIP-1, RIP-2, IGMP, static IPv4 routing, static IPv6 routing, RIPng, MLD
Remote Management Protocol	SNMP 1, SNMP 2c, HTTPS
Encryption Algorithm	WPA, WPA2
Features	DHCP support, NAT support, VPN support, PAT support, auto-uplink (auto MDI/MDI-X), Stateful Packet Inspection (SPI), DoS attack prevention, content filtering, MAC address filtering, IPv6 support, VPN passthrough, Wireless Distribution System (WDS) support, URL filtering, IP address filtering, firmware upgradable, MIMO technology, Spanning Tree Protocol (STP) support, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), IPSec NAT-Traversal (NAT-T), Wi-Fi Protected Setup (WPS), DHCP server, Samba support, FTP server, Multiple SSID support, MLD snooping, fanless, Stateful Packet Inspection Firewall (SPIF), Network Access Control (NAC), NTP time synchronization, Maximum Likelihood Demodulation (MLD), Class of Service (CoS), Denial of Service (DoS)
Compliant Standards	IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.1w, IEEE 802.11g, IEEE 802.1x, Wi-Fi CERTIFIED, IEEE 802.11e, IEEE 802.11n , EN55022 Class B, ICES-003 Class B, EN 301.489.1, EN 301.489.17, FCC Part 15.247, OET 65 C, RSS-210, RSS-102, FCC Part 15, UL 60950-1, EN 60950-1, EN 301.893, FCC Part 15.407, EN 60601-1-2, CAN/CSA C22.2 No. 60950-1, EN 62311, EN 300 328
Processor	1 x MIPS 700 MHz
Flash Memory	128 MB

Expansion / Connectivity

Interfaces

LAN : 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN : 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ USB : 1 x 4 pin USB Type A

Power

Power Device	External power adapter
Voltage Required	AC 120/230 V ( 50/60 Hz )
Power Consumption Operational	9.5 Watt

Miscellaneous

MTBF	51.54 years

Dimensions & Weight

Width	8.5 in
Depth	5.5 in
Height	1.5 in
Weight	15.87 oz

Manufacturer Warranty

Service & Support	3 years warranty
Service & Support Details	Limited warranty - advance parts replacement - 3 years - response time: next business day

Environmental Parameters

Min Operating Temperature	32 °F
Max Operating Temperature	104 °F
Humidity Range Operating	5 - 95% (non-condensing)
