JG219B | HPE 5820AF-24XG - switch - 24 ports - managed

HPE 5820AF-24XG - switch - 24 ports - managed - rack-mountable

(No reviews yet) Write a Review

Brand:

HPE

Part Number #

JG219B

Availability:

In Stock

$14,224.27 $11,853.56

- You save $2,370.71

Description
Read Before Ordering

Description

Main Specifications

Product Description	HPE 5820AF-24XG - switch - 24 ports - managed - rack-mountable
Device Type	Switch - 24 ports - L3 - managed - stackable
Enclosure Type	Rack-mountable 1U
Subtype	10 Gigabit Ethernet
Ports	24 x 1 Gigabit SFP/ 10 Gigabit SFP+ + 2 x 10/100/1000
Performance	Throughput (64-byte packet size) : 360 Mpps ¦ Routing/switching capacity : 484 Gbps ¦ Latency (64-byte packets) : 3 µs
Capacity	IPv4 routing table entries : 12000
MAC Address Table Size	32K entries
Routing Protocol	OSPF, BGP-4, IS-IS, RIP-1, RIP-2, BGP, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, static IP routing, PIM-DM, IGMPv3, OSPFv3, PIM-SSM, MSDP, VRRPE, policy-based routing (PBR), RIPng, MLDv2, MLD, IS-ISv6, BGP-4+
Remote Management Protocol	SNMP 1, SNMP 2, RMON 1, Telnet, SNMP 3, SNMP 2c, HTTPS, SSH, CLI
Features	Flow control, layer 3 switching, layer 2 switching, DHCP support, auto-negotiation, ARP support, load balancing, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack prevention, packet filtering, port mirroring, Weighted Round Robin (WRR) queuing, store and forward, IPv6 support, full duplex mode, Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), sFlow, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, DHCP server, MLD snooping, Equal-Cost Multipath (ECMP), Bidirectional Forwarding Detection (BFD), Unicast Reverse Path Forwarding (URPF), IPv4 support, Deficit Weighted Round Robin (DWRR), LLDP support, Link Aggregation Control Protocol (LACP), Port Security, NTP time synchronization, port isolation
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1x, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP)
Power	( 50/60 Hz )
Dimensions (WxDxH)	17.3 in x 26 in x 1.7 in
Weight	22.05 lbs
Manufacturer Warranty	1 year warranty
Bundled Services	1 year warranty

Extended Specifications

General

Device Type	Switch - 24 ports - L3 - managed - stackable
Enclosure Type	Rack-mountable 1U
Subtype	10 Gigabit Ethernet
Ports	24 x 1 Gigabit SFP/ 10 Gigabit SFP+ + 2 x 10/100/1000
Performance	Throughput (64-byte packet size) : 360 Mpps ¦ Routing/switching capacity : 484 Gbps ¦ Latency (64-byte packets) : 3 µs
Capacity	IPv4 routing table entries : 12000
MAC Address Table Size	32K entries
Routing Protocol	OSPF, BGP-4, IS-IS, RIP-1, RIP-2, BGP, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, static IP routing, PIM-DM, IGMPv3, OSPFv3, PIM-SSM, MSDP, VRRPE, policy-based routing (PBR), RIPng, MLDv2, MLD, IS-ISv6, BGP-4+
Remote Management Protocol	SNMP 1, SNMP 2, RMON 1, Telnet, SNMP 3, SNMP 2c, HTTPS, SSH, CLI
Encryption Algorithm	PKI
Authentication Method	Secure Shell (SSH), RADIUS, TACACS, Secure Shell v.2 (SSH2), HWTACACS
Features	Flow control, layer 3 switching, layer 2 switching, DHCP support, auto-negotiation, ARP support, load balancing, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack prevention, packet filtering, port mirroring, Weighted Round Robin (WRR) queuing, store and forward, IPv6 support, full duplex mode, Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), sFlow, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, DHCP server, MLD snooping, Equal-Cost Multipath (ECMP), Bidirectional Forwarding Detection (BFD), Unicast Reverse Path Forwarding (URPF), IPv4 support, Deficit Weighted Round Robin (DWRR), LLDP support, Link Aggregation Control Protocol (LACP), Port Security, NTP time synchronization, port isolation
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1x, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP)
RAM	2 GB - SDRAM
Flash Memory	512 MB

Expansion / Connectivity

Interfaces

2 x 1000Base-T - RJ-45 ¦ 1 x serial (console) - RJ-45 - management ¦ 24 x Gigabit / 10Gbit LAN ¦ 1 x USB 2.0 - Type A ¦ 1 x - RJ-45 - management

Power

Power Device	Internal power supply - hot-plug
Installed Qty	2 (max)
Voltage Required	( 50/60 Hz )

Miscellaneous

Compliant Standards

FCC Class A certified, ETSI, CISPR 22 Class A, GOST, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, NOM, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EMC, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, RoHS, FCC CFR47 Part 15, EN300-386, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, ANATEL, FDA, EN 60825-1, CAN/CSA C22.2 No. 60950-1, ANSI C63.4-2003, EN 60825-2

Dimensions & Weight

Width	17.3 in
Depth	26 in
Height	1.7 in
Weight	22.05 lbs

Manufacturer Warranty

Service & Support	1 year warranty
Service & Support Details	Limited warranty - advance parts replacement - 1 year

Environmental Parameters

Min Operating Temperature	32 °F
Max Operating Temperature	113 °F
Humidity Range Operating	10 - 90% (non-condensing)
