DJI Accessory CP.EN.00000224.01 MATRICE 300 PART05 BS60 Intelligent Battery Station
(No reviews yet)
Write a Review
- Brand:
- DJI
- Part Number #
- AS243692
- UPC:
- 190021017528
$1,224.00
Description
Key Features
•For DJI Matrice 300 RTK Batteries
•Requires USB Type-C Cable & Remote
•Charge 8 x TB60 & 4 x WB37 Batteries
•Hard-Shell Case with Built-In Wheels
•Built-In Carry & Telescoping Handle
•Padlock Holes for Improved Safety
•Automatic Pressure Valve
•Air Intake & Air Vent
•Status LEDs & Firmware Updateable
Charge all your batteries with this BS60 Intelligent Battery Station for Matrice 300 RTK from DJI. This hard-shell case can charge and protect up to eight TB60 flight batteries and up to four WB37 remote batteries with its 12 battery ports. Batteries are intelligently charged via a dual-volt AC plug and built-in circuitry that determines which batteries have the most power. For the top two TB60 and top WB37 battery, the BS60 will charge them first, ensuring you get airborne as soon as possible. Built-in wheels and a telescoping handle let you transport this battery charging station easily to where it's needed most.
Charging Operation
Activating the battery station requires an optional USB Type-C to USB Type-A cable to connect it to a Matrice 300 RTK remote controller. Once connected, press the power button and use the DJI Pilot app to activate charging.
Additional Features
Fully charge a TB60 battery in up to 70 minutes
Built-in padlock holes for added security with optional padlocks
Battery station securely closes via two built-in locking clasps
Built-in carry handle
Built-in pressure valve
Air intake and air vent
Status LEDs
Firmware updates via USB Type-C Protections
Anti-Backflow
Short Circuit
Overvoltage
Overcurrent
Temperature
Charging Time
100-120 V: Up to 70 Minutes (1 x TB60 Battery)
220-240 V: Up to 60 Minutes (1 x TB60 Battery)
Input Voltage
100-120 to 220-240 VAC at 50-60 Hz
Output Power
2 x TB60 at 100-120 VAC: 750 W, 52.8 V, 7 A
2 x TB60 at 220-240 VAC: 992 W, 52.8 V, 8.9 A
1 x WB37: 8.7 V, 6 A
Power
Without Load: Warming up the Battery: 52.8 V, 2 A
Operating Temperature
-4 to 104oF / -20 to 40oC
Ports
12 x Battery
1 x USB Type-C
Load Capacity
Maximum Load: Up to 26.5 lb / 12.0 kg
Item Dimension (L"xW"xH")
22 x 12 x 18
Weight
35 lbs
Warranty Information
1 year
View AllClose
•For DJI Matrice 300 RTK Batteries
•Requires USB Type-C Cable & Remote
•Charge 8 x TB60 & 4 x WB37 Batteries
•Hard-Shell Case with Built-In Wheels
•Built-In Carry & Telescoping Handle
•Padlock Holes for Improved Safety
•Automatic Pressure Valve
•Air Intake & Air Vent
•Status LEDs & Firmware Updateable
Charge all your batteries with this BS60 Intelligent Battery Station for Matrice 300 RTK from DJI. This hard-shell case can charge and protect up to eight TB60 flight batteries and up to four WB37 remote batteries with its 12 battery ports. Batteries are intelligently charged via a dual-volt AC plug and built-in circuitry that determines which batteries have the most power. For the top two TB60 and top WB37 battery, the BS60 will charge them first, ensuring you get airborne as soon as possible. Built-in wheels and a telescoping handle let you transport this battery charging station easily to where it's needed most.
Charging Operation
Activating the battery station requires an optional USB Type-C to USB Type-A cable to connect it to a Matrice 300 RTK remote controller. Once connected, press the power button and use the DJI Pilot app to activate charging.
Additional Features
Fully charge a TB60 battery in up to 70 minutes
Built-in padlock holes for added security with optional padlocks
Battery station securely closes via two built-in locking clasps
Built-in carry handle
Built-in pressure valve
Air intake and air vent
Status LEDs
Firmware updates via USB Type-C Protections
Anti-Backflow
Short Circuit
Overvoltage
Overcurrent
Temperature
Charging Time
100-120 V: Up to 70 Minutes (1 x TB60 Battery)
220-240 V: Up to 60 Minutes (1 x TB60 Battery)
Input Voltage
100-120 to 220-240 VAC at 50-60 Hz
Output Power
2 x TB60 at 100-120 VAC: 750 W, 52.8 V, 7 A
2 x TB60 at 220-240 VAC: 992 W, 52.8 V, 8.9 A
1 x WB37: 8.7 V, 6 A
Power
Without Load: Warming up the Battery: 52.8 V, 2 A
Operating Temperature
-4 to 104oF / -20 to 40oC
Ports
12 x Battery
1 x USB Type-C
Load Capacity
Maximum Load: Up to 26.5 lb / 12.0 kg
Item Dimension (L"xW"xH")
22 x 12 x 18
Weight
35 lbs
Warranty Information
1 year
